Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: lintratek repeater
  • Model Number: KW20L-DCS mobile signal booster
  • product attribute: cellular fullband booster dcs repeater
  • product size: 129*95*30mm
  • gain: 70dbi
  • output power: 20dbm
  • net weight: 0.6kg
  • frequancy: UL:1710-1785mhz;DL:1805-1880mhz
  • coverage: 200-500sqm
  • connector: N-Female connector
  • certificate: CE,ISO
  • quality warranty: 12 months

Packaging & Delivery

Packaging Details: Standard neutral packing
Delivery Detail: Shipped in 1 days after payment
Product Description

mobile signal booster/cell phone repeater/LTE1800MHZ 4G mobile booster with LCD display/lte booster repeater gsm



Specification should care about :



   Model No

KW20L-DCS mobile signal booster

Parameter data

Uplink

Downlink

Frequency Range

DCS

1710-1785mhz

1805-1880mhz

Output Power

20±2dBm

20±2dBm

Gain

70 ±2 dB

70±2dB

Bandwidth

75M

Ripple in Band

≤5dB

Spurious Emission

9KHz~1GHz

-36 dBm

1GHz~12.75GHz

-30 dBm

VSWR

≤3

MTBF

>50000 hours

Power Supply

AC:100~240V, 50/ 60Hz;DC:5V 1A

Power Consumption

< 5W

Impedance

50 ohm

Mechanical Specification

RF Connector

N-Female N

Dimensions (D*W*H )

140*95*30(mm)

Net weight

< 0.45Kg

Packing size (D*W*H )

250*240*65(mm)

Gross weight

< 0.7Kg

Installation Type

Wall Installation

Environment Conditions

IP40

Humidity

< 90%

Operating Temperature

-10°C ~ 55°C
