Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: lintratek
  • Model Number: KW23A-GW gsm repeater
  • gain: 70dbi
  • output power: 23dbm
  • product size: 195*175*23
  • packing size: 300*255*85mm
  • net weight: 1.5kg
  • frequancy: UL:890-915/1920-1980;DL:935~960/2110-2170
  • coverage: 200-500sqm
  • connector: N-Female connector
  • certificate: CE,ISO
  • quality warranty: 12 months

Packaging & Delivery

Packaging Details: Standard neutral packing
Delivery Detail: Shipped in 2 days after payment

Product Description

lintratek gsm wcdma 2g 3g gsm repeater dual band transmitter and receiver mobile signal booster



                                                 Specification

   Model No

KW23A-GW mobile signal booster

Parameter data

Uplink

Downlink

Frequency Range

GSM+WCDMA

890-915/
1920-1980 MHz

935-960/2110-2170 MHz

Output Power

10dBm

17dBm

Gain

65±2 dB

65±2dB

Bandwidth

60M

Ripple in Band

≤5dB

Spurious Emission

9KHz~1GHz

-36 dBm

1GHz~12.75GHz

-30 dBm

VSWR

≤3

MTBF

>50000 hours

Power Supply

AC:100~240V, 50/ 60Hz;DC:5V 1A

Power Consumption

< 5W

Impedance

50 ohm

Mechanical Specification

RF Connector

N-Female N

Dimensions (D*W*H )

140*95*30(mm)

Net weight

< 0.45Kg

Packing size (D*W*H )

250*240*65(mm)

Gross weight

< 0.7Kg

Installation Type

Wall Installation

Environment Conditions

IP40

Humidity

< 90%

Operating Temperature

-10°C ~ 55°C
